Main
Main Input Voltage 230 V
Main Output Voltage 230 V
Rated power in W 1200 W
rated power in VA 2000 VA
Product or component type Uninterruptible power supply (UPS)
Output connector type Hard wire 3-wire (1P + N + E) 1
Cable length 1.5 m
Range of product Back-UPS
Batteries & Runtime
Number of battery filled slots 0
Number of battery free slots 0
Battery voltage 24 V
Battery charger power 576 W rated
Extended runtime 0
General
Provided equipment user manual
Number of power module free slots 0
Number of power module filled slots 0
Redundant No
Physical
Colour Black
Height 22 cm
Width 14.5 cm
Depth 39.2 cm
Net weight 13.4 kg
Mounting preference No preference
Product datasheet
Two post mountable 0
USB compatible No
Input
Network frequency 40…70 Hz auto sensing
Plug standard India 3-pin 16A
Input voltage limits 140…300 V
Output
Maximum configurable power in W 1200 W
Output frequency 50 Hz +/- 1 Hz unsynchronised
UPS type Line interactive
Wave type Stepped approximation to a sinewave
Efficiency 92 % (full load)
Maximum configurable power in VA 2000 VA
Transfer time 8 ms typical : 12 ms maximum
Conformance
Product certifications BIS
Environmental
Ambient air temperature for operation 0…40 °C
Relative humidity 0…95 % non-condensing
Operating altitude 0…3000 ft
Ambient air temperature for storage 0…45 °C
Storage Relative Humidity 0…95 % non-condensing
Storage altitude 0…914.4 m
Acoustic level 50 dBA
IP degree of protection IP20
Communications & Management
Control panel LED Status display with on line : on battery
Surge Protection and Filtering
Surge energy rate 160 J
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 33.5 cm
Package 1 Width 23.5 cm
2Package 1 Length 47.7 cm
Package 1 Weight 14.3 kg
Contractual warranty
Warranty 2 years repair or replace
