Brand: Luminous
-
Product SKU / Model: LD3000-INX
-
Type: True Double-Conversion Online UPS (Single Phase)
-
Capacity: 3000 VA / 2400 W
-
Input Voltage Range: 110 V – 300 V AC (wide)
-
Input Frequency Range: 40 Hz – 60 Hz
-
Output Voltage: 220 V AC (also configurable for 200/230/240 V)
-
Output Frequency: 50/60 Hz ± 3 Hz
-
Output Waveform: Pure Sinewave
-
Output Power Factor: 0.8
-
Efficiency: ≥ 88 %
-
Load Crest Ratio: 3:1
-
Battery DC Bus Voltage: 72 V
-
No. of Batteries Required: 6 external batteries (user-supplied)
-
Battery Type: SMF / VRLA compatible
-
Maximum Charger Capacity: Up to ~6 A selectable
-
Communication: USB/RS-232 ports (optional SNMP)
-
Dimensions (D × W × H): ~397 × 145 × 220 mm
-
Weight: ~7.4 kg
-
Technology / Features: Microprocessor control, input power factor correction, automatic bypass, generator compatible
Luminous LD3000 INX UPS, 8 KVA
Roll over image to zoom in
The Luminous LD3000-INX Online UPS (3 KVA / 2400 W) is a true online double-conversion UPS designed to provide pure sinewave output and wide-range voltage protection for critical systems such as servers, networking equipment, and industrial electronics. With a wide input voltage tolerance, high efficiency, selectable charger settings, and communication ports for monitoring, it ensures reliable, uninterrupted power backup and protection against mains fluctuations.
