Brand: Luminous
-
Product SKU / Model: LD6000-Pro
-
Type: True Double-Conversion Online UPS
-
Capacity of Online UPS: 6000 VA / 5.4 kW
-
Output Phase: Single Phase
-
Output Voltage: 230 V AC (configurable for 200/220/240 V)
-
Output Power Factor: ~0.9
-
Output Waveform: Pure Sinewave
-
Input Voltage Range: 110 V – 300 V AC (wide)
-
Input Phase: Single Phase
-
Input Frequency Range: 40 Hz – 60 Hz
-
Battery DC Bus Voltage: 192 V DC (external batteries required)
-
Battery Type Compatibility: SMF VRLA / external batteries (user-supplied)
-
Maximum Charger Capacity: ~6 A
-
Current Crest Ratio: ~3:1
-
Efficiency (Approx.): > 88 %
-
LCD / Display: Multifunction LCD status & control panel (optional SNMP)
-
Noise Level: < 50 dB @ 1 m
-
Dimensions (Approx): ~367 × 190 × 318 mm
-
Weight: ~12 kg
-
Technology / Features: Microprocessor control, input power factor correction, wide input voltage range, generator compatible, automatic bypass, optional communication cards
Luminous LD6000-Pro Online UPS
Roll over image to zoom in
The Luminous LD6000-Pro Online UPS (6 KVA / 5.4 kW) is a true double-conversion online UPS that delivers pure sinewave power with a high output power factor for critical single-phase loads. Designed with a wide input voltage range, microprocessor control, and robust efficiency, it supports external SMF/VRLA batteries (192 V) for extended backup runtime and is ideal for servers, networking equipment, and industrial electronics in environments with fluctuating mains power.
